IMOU WiFi CCTV Kit-Pro monitoring kit

WiFi CCTV Kit-Pro IMOU

The MOU Kit-Pro is a surveillance system with four IMOU Bullet 2C cameras and a Wi-Fi NVR that allows for quick setup without complicated installation. The cameras record in 1080P Full HD (2MP) quality, and automatic pairing takes about 120 seconds, making setup simple and requiring no advanced knowledge. The built-in 1TB drive allows you to start recording immediately, while H.265 compression allows you to store more footage without quickly filling up the memory. A Wi-Fi range of up to 100m in open spaces and an IP67 rating make the kit suitable for both indoor and outdoor use.

Detailed image and wide field of view

The cameras use a 1/2.8" 2 MP Progressive CMOS sensor and record images at a resolution of 1920 × 1080. The viewing angle of 102° horizontally, 54° vertically and 120° diagonally allows you to cover a wide area without the need to install additional devices. Smooth recording up to 25/30 fps ensures clear images, which is important when analyzing events.

Monitoring even after dark

Night vision with a range of up to 30 meters allows you to monitor your surroundings even in the dark. This makes the system suitable for areas requiring constant surveillance – regardless of the time of day.

Stable connection and quick setup

IEEE802.11 b/g/n (2.4 GHz) connectivity and dual antennas ensure stable system operation. A range of up to 100 meters in open space allows for flexible camera placement. Automatic pairing simplifies setup and reduces the need for manual configuration.

Practical functions

The system detects motion and sends notifications to your phone, allowing you to quickly check for events. Features such as recording scheduling and playback of footage from all channels are also available. The cameras have a built-in microphone and support microSD cards up to 256 GB, allowing for additional recordings to be saved directly to the device.

Efficient recording and larger capacity

The recorder uses H.265/H.264 compression, which helps reduce disk space consumption. A built-in 1TB drive allows for long-term recording storage, and support for media up to 8TB via the SATA port allows for expansion. Recording speeds of up to 40Mbps (wired connection) and 16Mbps via Wi-Fi ensure stable system operation.

Functional recorder and remote access

The recorder is equipped with HDMI and VGA ports (up to 1080P), an RJ-45 network port (10/100 Mbps), RCA In and RCA Out connectors, and two USB 2.0 ports. It supports OSD functions, various recording modes (manual, alarm, scheduled), and backup via USB or network. Cloud access allows for live viewing and playback of recordings from anywhere.

Included:

• 4x Camera
• Wi-Fi NVR (with built-in 1TB HDD)
• Quick Start Guide
