Uni-T UT207B Digital Clamp Meter

  • Watch the product:
  • Add feedback:
  • Code: INN_57903
  • Manufacturer: UNI-T
  • Availability: 1 working day
  • 99.76 EUR
  • szt.

BUY NOW AND CREATE YOUR DREAM HOME. DO IT NOW IN 3 SIMPLE STEPS.

Your purchases will be delivered by DPD Courier.

You can pay for your purchases with credit card or bank transfer using safe PayU system or bank transfer.

You've made a good choice. However, if you return the product within 14 days, you'll receive a full refund.

Uni-T UT207B Digital Clamp Meter

The Uni-T UT207B digital clamp meter is a universal tool for working with electrical installations and device diagnostics. Its clamp-on design allows for quick current measurement without disconnecting the circuit, significantly simplifying work in the field and at distribution boards.

UNI-T digital clamp meter held in an electrician's glove during testing in a control cabinet.

Functions that make your work easier

The UT207B is designed for the most demanding applications, enabling precise measurement of AC and DC current up to 1000A and AC/DC voltage up to 1000V. With a wide range of electrical parameters and advanced features such as True RMS, Zero Mode, NCV, and LPF and LoZ filters, the device guarantees the highest accuracy even in challenging conditions. Additionally, the built-in inrush current measurement function allows for detailed analysis of transient loads.

UNI-T meter on a black countertop measuring components on a green PCB.

Clear design and safety

A large display with a bargraph and a robust construction ensure ease of use. The device meets CAT III 1000V / CAT IV 600V standards.

UNI-T clamp multimeter in an electrician's hand, aimed at thick electrical wires.

Included

  • Clamp Meter
  • Battery x3
  • Test Leads
  • User Manual

Specification

ManufacturerUni-T
ModelUT207B
TypeTrue RMS Clamp Meter
AC Current1000A ±(2%+5)
DC Current1000A ±(2%+5)
Inrush Current1000A ±(10%+10)
AC Voltage1000V ±(1.2%+3)
DC Voltage1000V ±(0.5%+5)
LPF ACV1000V ±(2%+5)
LoZ ACV1000V ±(2%+5)
AC Voltage Bandwidth40Hz ~ 400Hz
Resistance60MΩ ±(1%+2)
Capacitance60mF ±(4%+5)
Frequency10Hz ~ 1MHz ±(0.1%+3)
Duty Cycle10% ~ 90% ±(2.6%+7)
Maximum Reading6000
FunctionsTrue RMS, NCV, LPF, LoZ, Zero Mode, Inrush Current Measurement, Bargraph
Jaw Opening42 mm
Power Supply3x 1.5V (R03) battery
Display43 x 45 mm
Dimensions272 x 81 x 43.5 mm
Weight420 g
SafetyCAT III 1000V / CAT IV 600V
CertificatesCE, UKCA, cETLus
